Catamaran Marina Bay Yachts

Salon

• Lighting overhead  (LED) 110 Volt
• Flooring  Underlay plywood with finished flooring wood/vinyl
• Wall finish 1/2" sheetrock or approved panels.  Painted with interior latex flat paint if not pre-finish
• Side windows opening tempered, tinted glass (single sliding window)
• Wine cooler U line at stairwell bulkhead
• Garbage compactor at stairwell bulkhead
• Entertainment cabinet in two stateroom model. Drawers/storage. Pre wired TV and sound
• Entertainment JL System Bluetooth Airplay Stereo with Speakers   Pre-wired for TV installation

Galley

• Lighting overhead (LED) 110  Volt
• Galley cabinets.  High grade finish with cabinets and drawers above and below the sink per design
• Dish washer    Fisher Paykle or equal brand
• Micro wave   convection   GE or equal
• Induction cooktop Electric  3 elements.
• Range hood and exhaust system over cooktop.  Princess or equal
• Refrigerator. Full size & separate freezer compartment
• Sink Stainless Steel  Double compartment with garbage disposal
• Solid surface counter top
• Water filter for galley sink and ice maker
• 110 volt outlets GFI protected

Mater Stateroom

• Lighting overhead (LED) 110 Volt
• Reading lights (2) at bedhead 110 Volt
• Private entry doors (2)  (one bedroom model) (Starboard door sized)  3" 0"
• Private entry doors (1)  (two bedroom model) (Door size)  3" 0
• Hatches to pontoon   (As need to access all compartments)
• Side windows opening (1)  tempered, tinted glass (single sliding window)
• Bed built in Queen size with storage under.   (Option to buyer)
• Night stand cabinets each side of bed with draw storage.   (Option to buyer)
• Sliding door 8' anodized with tempered glass.  Locking from inside.  Screen for opening
• Wall and ceiling finish  Sheet rock 1/2" with stipple finish or a pre-finished panel or equal panels
• Floor  Plywood subfloor with wood/ vinyl finish
• Closet for MSR in head for single cabin layout.  In MSR for two cabin layout
• Entertainment JL Stereo system and speakers.  Pre-wire for TV installation

Head Master

• Vacu flush toilet with switch at helm for overboard pump out and deck fitting for dockside pump out
• Lighting overhead (LED) 110 Volt
• Sink, faucet and cabinet
• Medicine cabinet set in bulkhead with mirror
• Tub and shower with flexible shower attachment.  Grab rails
• Shower curtain and rod  for tub and shower
• Door to head to be 3' 0"
• Flooring Vinyl Wood
• Towel holder
• Toilet paper holder
• Ventilation fan to outside
• 110 Volt outlets GFI protected
• Side windows opening  tempered, tinted glass
• Light switching at door opening.  Auto on with entry and off
• Solid surface counter top
• Drain in floor direct to outside
• Grab rails

Guest Stateroom

• Lighting overhead (LED)
• Reading lights at bedhead each side
• Private entry door (Single door 2' 6") (two bedroom model)
• Hatch to pontoon (as needed to access all compartment
• Side windows opening (1)  tempered, tinted glass (single sliding window)
• Closet  with pole and shelf.  Cedar lined.
•  Wall and ceiling finish  Sheet rock 1/2" with stipple paint finish.
• Floor  Plywood subfloor with wood/vinyl finish

Head Half (optional)

• Vacu flush toilet with switch at helm for overboard pump out and deck fitting for dockside pump out
• Sink with faucet.  Open space under the sink.  Medicine cabinet with mirror
• Mirror
• Ventilation fan to outside
• Toilet paper holder
• Towel holder
• Lighting LED
• Outlet 110 Volt GFI
• Access door 2' 6"

General Specifications

• Anti fouling paint. Epoxy primer and 1 coat bottom paint
• Deck surfaces to be FRP Non skid or equal
• Insulation throughout sprayed with expanding foam
• Hatches to all compartments

Helm - Midship

• Suitable presentation for future electronics
• Helm seat for two.  Single seat for two or two helm chairs
• Suzuki Digital Display
• JL Am/FM Bluetooth Airplay Stereo with speakers
• Grab Rails
• Lighting Courtesy LED Blue
• Charge ports for cell
• Storage under helm
• Compass 4.75"
• VHF ICOM
• Circuit breaker panel for future electronics with a power feed from the house battery bank  (6 breaker

Construction

• Catamaran Hull. Solid Molded hand laid fiberglass. Cloth, woven roving and matt materials. Solid bulkheads. Keel added inside. Capped full length.
• Compartments throughout each pontoon.  (Finished (Gel Coated) interior of compartments with Hatches 4)
• Vinylester resin first layer of laminate
• Isophalic gel coat (white)
• Superstructure: FRP panels (Exterior) adhesived to 7/16 Roof and Wall sheathing, Trade name. Zip System. Adhesived & screwed to 2" x 4" & 2" x 6" studs.
• Floor Deck Aluminum joists bolted to FRP pontoons. Equal to 2 x 8" @ 16" OC  Plywood T&G to aluminum frames.  Joists are thru bolted to the tab on the pontoons. The superstructure is thru bolted to the joists.
• Upper Decking  2" x 10" DF 16" OC or 9.5" TJI/110 @ 16" OC with blown in insulation. 3/4" T&G Ply Exterior Grade
• Tie downs or equal at each corner and at each end of interior walls.
• Decking material. Fiberglass or Lon Seal from Carson, Ca or equal
• Cleats (12" midship on rub rail (2) on port and starboard. Spaced evenly between bow and stern decks.  Thru bolted with metal brackets connecting to cross timber deck supports.  Total per side with deck cleats on deck
• Water tight collision bulkhead  forward in each pontoon
• Interior walls: panels sheetrock 1/2" or equal.  Textured or stipple finish.
• Double welded and bolted aluminum floor joists at each end wall. Added heavy duty plate added for further reinforcement.

Bow Deck

• Windlass  vertical with overload protection Maxwell equal.  Rope or chain. Up and down on deck
• Anchor with cruise safety strap
• Bow roller
• Chain lock under bow deck in wave piercing mold.  Deck Hatch with overboard drain
• Cleats Stainless Steel  12" each side of decks
• Deck FRP Non Skid or  equal
• LED Lighting 12 Volt
• LED Lighting 110 Volt
• Self  Draining Openings sized per Coast Guard USA  (if deck is enclosed)
• Waive piercing attachment attached to floor joist system.  Holding anchor chain.   3/8" BBB 200'
• A clear panel in the forward enclosure approx. 3' x 8'.  Open view from the Master Stateroom

Aft Deck

• Twin outboard engines
• Deck FRP Non Skid or equal
• Side gates to the dock port and starboard.  Anodized Aluminum Swing in
• Gate (rails stern)to dock and sides at engines stern to the dock
• Rails Stainless Steel with mid rail
• Cleats Aluminum Anodized 12" each side of deck
• Storage box or compartment for generator. Vented per generator specifications
• Generator  Brand and size to be determined for electric requirements of the vessel in a compartment
• LED lighting 12 volt
• LED lighting 110 volt including flood lights
• Hand held shower hot and cold (fresh water)
• Self draining openings sized per Coast Guard USA
• Fresh water inlet
• Entry to saloon to be a single 3' 0' glass door with key lock and a  window to port side or an 8' sliding saftey glass

Upper Deck

• Stairwell with grab rails/lighting, Non skid steps
• Helm station with engine controls and gauges
• Helm seating for two.  Bench seating
• Rails around the deck  Anodized with mid rail or screen
• Deck  FRP Non skid or other approved deck material for walking on.
• LED Lighting 12 Volt
• LED Lighting 110 Volt
• Electric control breaker panel at helm with 12 volt breakers for electronics.  Single cable to battery source

Electrical

• Batteries (maintenance free) 12 volt engine start, house and Generator start
• Battery banks isolated by manual isolators
• Battery charger, automatic, 30 amp for start and auxiliary
• Invertor  3000 watt minimum for Entertainment system, TV, 2 galley outlets, refrigerator
• Battery paralleling system for emergency engine starting. ( See Suzuki)
• Zinc anodes as needed
• Engine instrumentation at helm
• Light switches for all 12 and 110 volt lights.  USA
• Light fixtures throughout .   LED
• Wiring coded, numbered.  Organized in looms for ease of visual inspection
• Navigation lights LED (international standard)
• All electric with Residual Current Device (RCD) protection
• Shore power inlet starboard aft at stairwell.    30 amp 110 volt or 240 amp. Dockside supply to be either
• Circuit panel   BEP located inside at stairwell bulkhead or equal
• Generator. Muffler, fresh water cooled, sound shield, remote start/stop and hour meter
• AC system built 110v/220V 50 amps
• Electric panel 110 and 220 volt.  12 volt DC    BEP or equal

Electronics

• VHF Garmin with Antenna
• Camera to forward and aft deck to screen at helm. Pre-wire if not available
• Pre-wire for future dealer or factory installed Garmin electronics

Mechanical

• Hot water heater (fresh) 12 gallon Electric 110 Volt
• Fresh water pump DC
• Fresh water system   200 gallons minimum in plastic tanks
• Fuel shut off at tanks
• Fuel fill aft deck (locate best possible for ease of fueling and safety)
• Fuel tanks  (2) USCG aluminum tanks in a fire retardant fiberglass enclosure  400 gallons baffled
• Holding tank Black water  100 gallon baffled
• Holding tank Black water     Macerator pump installed inline for overboard or dockside pumpout.
• Dockside vacuum pump out with deck fitting on each side of aft deck
• Pump out system with switch at helm for pumping overboard underway
• Venting for holding tank to be at highest point on the vessel with filters as needed
• Bow & Thrusters  12 v electric (2) port and starboard
• Engine Controls at helm.  Optional:  controls on aft deck.   Pre-wire
• Rails  Anodized Aluminum White
• Fuel Lines Swagged
• Fuel Manual site gauges fixed to tank
• Visual and audible signal for high water
• Air conditioning/heat to be determined as to size and number of units to serve all areas
• Sea water strainers for generator, air conditioning
• Fresh water inlet aft deck for dockside water inlet.  Pressure control fitting installed

Entertainment

Pre wire for TV in saloon, staterooms and aft deck.  Provide a 110 outlet for each TV at agreed to location

Laundry

Washer dryer  Stacked   GE or equal  Vented to outside.   (Installed in MSR closet or Master Head with a shower)

Engines

• Yamaha (2) 300 HP with Joystick controls, OPS, Auto Pilot, Electric Steering
• Cox Diesel (1) or (2) 300 HP

Misc.

• Fenders (4)
• Dock lines (6)
• Gelcoat (1 quart white)
• Owners manual
• Fire extinguishers (4)
• Smoke detectors
• CO2 detectors

Warranty

• Marina Bay Yachts subject to the terms and conditions of their warranty policy with replace and repair defects caused by faulty workmanship and materials during the first 12 months after delivery.
• This same policy will apply to Catamaran hull details for 5 years from the date of delivery to the customer.
• All equipment installed on the vessel is warrantied by the manufacturer of that equipment.
• Suzuki warranty extends for 6 years to the the original purchaser.  See their complete warranty policy.
• All warranty's are provided to the first retail purchaser.

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
